Plain Sheets & Coils




Overview
There are four types of roll width available from many gauges, and you can get plain sheets according to customer requirements. Plain sheet and coil is the starting point for gutters, flashings, ducting and the countless fabricated components a building needs.
Buying full-width coil and trimming it down wastes both material and labour, so supplying the width you actually work in removes that waste at source. Because it comes from the same coated stock used for our roofing profiles, a fabricator making a flashing gets material with the identical coating specification and colour as the roof it will sit against.
Available in Alu-zinc coated and hot dipped galvanised material, plain or colour coated.
Technical Data
Confirm final dimensions and tolerances with our technical team before ordering — sheets are manufactured to your measured lengths.
Roll widths
Four standard roll widths
Gauges
Many gauges available
Plain sheet
Supplied to customer requirements
Substrate
Alu-zinc coated or hot dipped galvanised (GI)
Standards
JIS G 3321 / ASTM A792 / ASTM A755 G550
Thickness
0.13 mm – 0.47 mm (up to 0.7 mm subject to quantity)
Finish
Plain or colour coated
